Specification

XTR5 and XTR7 Airless Spray Gun
U.S.
Metric
Maximum working pressure:
35 MPa, 345 bar
XTR 7 7250 psi
50 MPa, 500 bar
Fluid orifice
2.3 mm
Fluid inlet
1/4 npsm (m)
Max. fluid temperature
71°C
Sound pressure
84.3 dB(A)*
Sound power
95.7 dB(A)*
Wetted parts
aluminum, stainless steel, acetal, polyethylene, nylon, polypropylene, carbide, polyurethane, solvent-resistant o-rings.
*Results are maximum readings taken at 6000 psi (41 MPa, 414 bar), with HD519 tip, using water. Sound power level was tested to ISO 9614-2.
